01 / 05Granulation · GHL series
High Shear Wet Mixing Granulator
A horizontal high shear mixer granulator. It mixes dry powder, adds binder and forms granules in one cylinder.
- Volume
- 10 L to 600 L, 8 models
- Batch
- 3 kg to 300 kg
- Cycle
- Dry mix 2 min, granulate 1 to 4 min
- Granule size
- 20 to 80 mesh
- Built to your materialSize, material and motor set to your product.
- Made in our workshopDesigned and built by our own team.
- Support through installationFrom first inquiry to your production line.
Overview
Mix and granulate in one cylinder
The GHL wet mixing granulator is a horizontal cylinder machine for pharmaceutical, food and chemical powder. A mixing paddle and a cutter work together to make granules after the binder is added.
Compared with a traditional process it uses about 25 percent less binder and works 4 to 5 times faster.
Dry mix
Powder is mixed for about 2 minutes.
Add binder
Binder is added while the paddle and cutter turn.
Granulate
Granules form in 1 to 4 minutes and are discharged.
The range in numbers
- 8Models
From GHL-10 to GHL-600
- 3 to 300kg
Per batch
- 4 to 5 timesEfficiency
Versus traditional process
- 25%Less binder
Than traditional process
More views
Have a question about this machine?
Send your material and batch size. We reply with a suitable model.
Features
Less binder, fewer steps
An air filled seal protects the shaft.
- 01
One cylinder
Mixing and granulating happen in a single horizontal cylinder.
- 02
Air sealed shaft
An air filled shaft seal keeps powder out of the bearing.
- 03
Less binder
About 25 percent less binder than the traditional process.
- 04
Short cycle
Dry mixing takes 2 minutes and granulating takes 1 to 4 minutes.
- 05
High efficiency
4 to 5 times the efficiency of the traditional process.
- 06
Even granule
Granule size is 20 to 80 mesh.
Build it your way
Size
Eight models from 10 L to 600 L.
Power
Two speeds for blending and cutting.
Granule size
20 to 80 mesh.
Control
Options to suit your line.
GMP
The machine meets GMP requirements.
Have a question about this machine?
Send your material and batch size. We reply with a suitable model.
Specifications
Choose by batch size
Cutting speed is 1440 / 2900 r/min and working time is 8 to 15 minutes on all models. Values with a slash are low / high speed.
| Model | Volume (L) | Capacity (kg/batch) | Blending speed (r/min) | Blending power (kW) | Cutting power (kW) |
|---|---|---|---|---|---|
| GHL-10 | 10 | 3 | 300 / 210 | 1.5 / 2.2 | 0.85 / 1.1 |
| GHL-50 | 50 | 15 | 300 / 210 | 4 / 5.5 | 1.5 / 2.2 |
| GHL-150 | 150 | 50 | 270 / 180 | 9 / 11 | 2.4 / 3 |
| GHL-200 | 200 | 80 | 270 / 180 | 11 / 14 | 3.3 / 4 |
| GHL-250 | 250 | 100 | 188 / 130 | 11 / 14 | 3.3 / 4 |
| GHL-300 | 300 | 130 | 160 / 110 | 11 / 14 | 4.5 / 5.5 |
| GHL-400 | 400 | 200 | 120 / 85 | 15 / 17 | 6.5 / 8 |
| GHL-600 | 600 | 300 | 120 / 80 | 22 / 30 | 9 / 11 |
Showing 7 of 8 models
Have a question about this machine?
Send your material and batch size. We reply with a suitable model.
Applications
Where it works
It makes granules from powder in pharmaceutical, food and chemical plants.
Materials it handles
Have a question about this machine?
Send your material and batch size. We reply with a suitable model.
Questions
Before you order
01What does it do?
It mixes dry powder and makes granules in one horizontal cylinder.
02How long is a cycle?
Dry mixing takes about 2 minutes and granulating takes 1 to 4 minutes.
03How much binder does it save?
About 25 percent compared with the traditional process.
04How fast is it?
4 to 5 times the efficiency of the traditional process.
05What granule size?
20 to 80 mesh.
